Aircraft Warning Sphere Installation Case: AH-AWS 600 mm Fiberglass Markers on High-Voltage Transmission Lines
Diterbitkan pada: October 29, 2026
Q&A: Aircraft Warning Sphere Installation on High-Voltage Transmission Lines
Q1 What is it for? Marking overhead conductors of 110-500 kV transmission lines, river crossings and tall pylons so pilots can see the wires in time.
Q2 Key specification? 600 mm diameter sphere in fiberglass-reinforced polyester, 2.3 mm wall, 6.3 kg, bright orange, red or white.
Q3 Why fiberglass? Tensile strength ≥128 MPa, bending ≥230 MPa and a -40 to +90 °C range, with uniform wall thickness that stays stable under aeolian vibration.
Q4 How is it mounted? Split shell clamped by stainless bolts, nuts and washers (M10×35 / M10×40) over an 800 mm aluminium-alloy armor rod; suits conductors of 10-35 mm.
Q5 Weather performance? Drain holes under the sphere release rainwater so no water stays inside, and the UV-stable resin keeps the warning colour bright.
Q6 Compliance? Marking per ICAO Annex 14 (Aerodromes), with other diameters available on request.
